On September 11th, the 25th China International Optoelectronic Expo (hereinafter referred to as: CIOE China Optoelectronic Expo), which has attracted a lot of attention, was grandly opened in Shenzhen International Convention and Exhibition Center (Bao'an New Venue).
PolarisIC brought a variety of cutting-edge chips and modules in the two core areas of depth sensing and micro-optical imaging to the exhibition, attracting many people inside and outside the industry to stop, visit and consult in front of the pavilion, and gaining a high degree of attention.
PolarisIC's exhibition site
1New Products
DTS6004 is a multi-zone dToF module product, which supports 2×2 time division and zone acquisition of distance data. Relying on the high-performance dToF SoC and VCSEL transmitter, it can realize high-precision distance measurement within a range of 6m, with a frame rate of up to 30Hz, and excellent resistance to ambient light, which enables accurate distance measurement in complex environments.
DTS6004
02DTS6032 As a high-precision, long-distance measurement dToF compact module, the DTS6032 integrates a highly sensitive SPAD sensor and advanced algorithms, with a maximum range of 45m, and can maintain accurate measurements even in a 100KLux bright light environment. With a frame rate of up to 1000fps, the DTS6032 is the first choice for small ToF applications with extreme miniaturization and high performance.
DTS6032
2 Core Products Revealed
DTS6012M is a highly integrated and miniaturized dToF ranging module, integrating a highly sensitive SPAD sensor and advanced algorithms to achieve high-precision ranging and sunlight resistance of 12m@100KLux, with a range of up to 20m. Its ultra-small size, lightweight design, and flexible interfaces make it ideal for micro-small-scale dToF applications, and it is also equipped with reflectivity correction and TDC time window configuration functions to meet diversified application scenarios. It is also equipped with reflectance correction and TDC time window configuration to meet diversified application scenarios.
DTS6012M
The DTS6007M is a highly integrated miniature dToF SiP that integrates a dToF SoC with a VCSEL emitter and optics in a compact package measuring only 4.4 x 2.4 x 1.0 mm. The module is capable of high-precision distance measurements within a range of 4.5 m, with a frame rate of up to 120 Hz, and is capable of contaminant and reflectance calibration, and is easy to integrate. It can be widely used in cell phone laser assisted focusing, sweeper/AGV obstacle avoidance, and projector assisted focusing.
DTS6007M
Based on photon counting imaging technology, the new line array image sensor PCL7152 adopts a high sensitivity SPAD sensor, integrated center of mass algorithm and parallel high-speed data output, which is suitable for a variety of high-precision sensing applications such as laser displacement, liquid level detection, spectral confocal, as well as low signal-to-noise ratio environments such as floor sweeper and AGV obstacle avoidance. It is characterized by high sensitivity, high frame rate, direct digital output and rich center-of-mass information processing capability, and supports high-speed parallel data transmission and sunlight substrate subtraction, which can significantly improve the measurement accuracy and stability under complex optical fields.
PCL7152
3Application examples vividly presented
In this exhibition, PolarisIC demonstrated a variety of application scenarios such as projector trapezoidal correction, aircraft altimetry, new type of ToF photoelectric sensors, user detection in smart home control panels, dToF lighting control, dToF along-wall sensing, high-speed photography, and so on, which allowed the audience to experience the scientific and technological shock of the depth sensing and microluminescence imaging technology.
01 Projector Keystone Correction
PolarisIC's self-developed DTS6004 micro-module supports 2×2 partition to obtain distance information, which can help the projector realize automatic sensorless focusing and keystone correction. This simplifies the operation process, eliminating the need for tedious manual adjustments to enjoy a clear, distortion-free projection image and enhancing the overall user experience and satisfaction.
Projector Keystone Correction
02Flyer Height Setting
DTS6012M miniature module, known for its extreme lightweight design, weighs only 1.35g and combines the advantages of long-range detection, high-precision measurement, fast response, strong light resistance and ultra-lightweight. It can effectively help the aircraft to accurately sense obstacles and flight altitude in real time during the flight to ensure the safe and smooth flight of the aircraft.
Aircraft altitude fixing program
03 Diversified application scenarios of dToF module
Based on PolarisIC's self-developed DTS6007M miniature module, it is characterized by fast measurement speed, high precision and non-inductive measurement, and can be widely used in multiple scenarios.
New ToF photoelectric sensor
The new ToF photoelectric sensor integrated with DTS6007M module has significant advantages in terms of precision, anti-interference ability, anti-intensity of light characteristics and design integration. The sensor is not only applicable to the entrance and exit of gates, accurately sensing the flow of people in and out and efficiently counting the number of people, but also can be flexibly applied to the field of cargo counting. When the sensor is mounted on a reciprocating motor to simulate a conveyor belt environment, the photoelectric sensor can count quickly and accurately, regardless of the speed of the conveyor. It provides an efficient, reliable and flexible measurement solution for industrial automation and other scenarios.
New ToF Photoelectric Sensor
User detection in smart home control panels
Integrate dToF modules for user detection in smart home systems. When the user approaches, the dToF module senses the change in distance and triggers the system's screen to light up automatically, displaying parameters, setting information, etc., facilitating user interaction.
User Detection in Smart Home Control Panel
dToF lighting control
enables intelligent control of light switching and brightness by integrating DTS6007M in the gesture light. The module accurately detects the distance and presence of the hand, and automatically adjusts the light switch and brightness based on this distance, bringing convenience and intelligent experience to users' daily life.
dToF Light Control
04dToF Along Wall Sensing
DTS6005 has a stable performance, can easily cope with a variety of highly reflective material challenges, frame rate up to 30Hz, to ensure high-speed ranging ability. It has a high degree of accuracy, and the chip's ranging error can be controlled within ±3mm at a measuring distance of less than 15cm. This product can be used in sweeping robots, and is the best performance along-wall sensing solution for sweepers on the market today.
dToF Along-Wall Sensing
05High-speed photography
Based on PolarisIC Micro's self-developed large-face array PCI prototyping chip PCM5200, it can realize single-photon level sensitivity, combining excellent features such as high sensitivity, high frame rate, high dynamic range, high integration, low noise, etc., which can easily realize high-speed imaging, and at the same time, it can satisfy the needs of shooting in dark light environments, such as the star level, which brings a new vision and efficient solutions for industrial inspection, scientific research exploration and other fields.
High-speed photography
Through self-developed 3D visual sensing technology, PolarisIC will break through the product performance boundary with continuous technological innovation, and oriented to market demand, we are committed to letting efficient and high-performance chips serve various industries, and continue to empower the digital age of Internet of Everything. Realize win-win situation with customers.
The exhibition will continue until September 13th, during which PolarisIC will continue to present a series of impressive exhibits and cutting-edge applications to the audience. We sincerely invite all interested parties to visit our booth 6C59 to experience and learn more about our products, and look forward to exploring the infinite possibilities of visual sensing technology with you.
